SIMATIC ET 200MP IM 155-5 PN HF For up to 30 I/O modules, S2 redundanc

  1. SIEMENS 6ES7155-5AA00-0AC0 1003773
Piece
SIMATIC ET 200MP. PROFINET IO device Interface module IM 155-5 PN HF, for ET 200MP electronic modules Up to 12 IO modules without PS Up to 30 IO modules with additional PS Integrated 2-port switch RJ45 shared device MRP IRT <gt/>=0.25 ms Isochronous mode FW update I&M0...3 Prioritized startup, S2 redundancy Shared device with 4 controllers Suitable for operation with active backplane bus (FW V4.4 or higher) The SIMATIC ET 200MP is a modular and scalable I/O system with IP20 for universal use, and offers the same system advantages as the S7-1500. It permits the shortest bus cycle times and fastest response times, even with large volumes of data. The distributed I/O system is particularly easy to install, wire, and commission. Thanks to its scalable design, you can gear the IO station exactly to the on-site requirements. The interface modules connect SIMATIC ET 200MP to PROFINET or PROFIBUS, and exchange data between the higher-level controller and the I/O modules.
